CD1 MD1 Wire Rope Electric Hoist

The main features of electric wire rope hoist include:

1. Compact structure, lightweight, small volume, and international dimensions, making it easy to operate.
2. Easy installation and high efficiency, ensuring smooth operation.
3. Reducer with hard tooth surface driving design for long lifespan and high mechanical efficiency.
4. Motor with taper rotor brake and upper and down two-way security limit device for added safety.
5. Safe and reliable operation, providing peace of mind during use.
6. Low-cost maintenance and long working life, reducing overall operating expenses.
7. Available with both pendent control and remote control options for added convenience and versatility.

Min. order: 1 Piece

Payment: TT,LC,DA,DP

Shipment: Contact us to negotiate shipping details

Send email to us

Product Detail

Product Tags

Product Description

Model CD1,MD1 Wire rope Electric Hoist is a small-sized lifting equipment, which can be mounted on single beam, bridge, gantry and arm cranes. With slight modification, it can also be used as a winch. It is widely used in factories, mines, harbors,warehouses, cargo storage areas and shops, essential in raising working efficiency and improving working conditions.

Model CD1 Electric Hoist has only one normal speed, which can satisfy normal application. Model MD1 Electric Hoist provides two speeds: normal speed and low speed. At a low speed, it can do precise loading and unloading, mounding of sand box,maintenance of machine tools, etc. Thus, model MD1 Electric Hoist is more widely than Model CD1.

To meet the needs of lifting heavier cargo,our factory also manufactures HC type large tonnage electric hoist.

TYPE CD1 wire-rope electric hoist is a kind of small-lifting equipment.It can mounted on single beam overhead cranes.Gantry Cranes, Jib Type CD ,electric hoist as only one normal speed which can satisfy normal application. It is widely used in factories, mines, harbours, cargo storage area and shops,essential in raising working efficiency and improving working conditions.

Detail Display

1. Design: International advanced tide compact and nice.

2. Reduce: High strength hard gear surface, inclined gear driving with low noise.

3. Motor: Inside fit plane brake, double winding pole changing control motor, incorporate with reducer, suit higher classification.

4. Wire Rope: The tensile strength is 1760N/mm2.

5. Limit Switch: Cam limit model operate safety.

6. Working duty: A5/M5.

7. Speed: with Frequency inverter.

8. Main electrical parts: Schneider.

CD Hoists are specially designed for higher lifts, faster hoisting & cross travel speeds & moveable on curved tracks can be manufactured accord demand.

MOTORS: We offer hoist & crane duty Vz hour rated squirrel cage induction motors, confirming to IS 325 with comparatively higher H.P. and higher starting torque to reduce handling time. It is flange mounted to suit our design and with Class B or F insulation.

220V Machine Electric Hoist Lift for Single Beam Industrial Bridge Cranes:It is a small-sized lifting equipment, which can be mounted on all types of cranes,such as gantry crane, overhead crane, jib crane and other special crane to lift all types of material. With a small modification,it can also be used as a winch.What’s more, it can be installed easily with different heights by hand control.

Work Shop

Specifications

Model	SY-EW-CD1/SY-EW-MD1
Hoisting Capacity	0.5	1	2	3	5	10
Norm Working Level	M3	M3	M3	M3	M3	M3
Hoisting Height(m)	6 9 12 18 24 30	6 9 12 18 24 30	6 9 12 18 24 30	6 9 12 18 24 30	6 9 12 18 24 30	6 9 12 18 24 30
Hoisting Speed(m/min)	8;8/0.8	8;8/0.8	8;8/0.8	8;8/0.8	8;8/0.8	7;7/0.7
Operating Speed(suspended type)	20;20/6.7 30;30/10	20;20/6.7 30;30/10	20;20/6.7 30;30/10	20;20/6.7 30;30/10	20;20/6.7 30;30/10	20;20/6.7 30;30/10
Type and Power of Hoisting Electric Motor(kw)	ZDY11-4(0.8)	ZDY22-4(1.5)	ZDY31-4(3)	ZDY32-4(4.5)	ZD41-4(7.5)	ZD51-4(13)
	ZDS1-0.2/0.8(0.2/0.8)	ZDS1-0.2/1.5(0.2/1.5)	ZDS1-0.4/3(0.4/3)	ZDS1-0.4/4.5(0.4/4.5)	ZDS1-0.8/7.5(0.8/7.5)	ZDS1-1.5/1.3(1.5/1.3)
Type and Power of Operating Electric Motor(suspended type)	ZDY11-4(0.2)	ZDY11-4(0.2)	ZDY12-4(0.4)	ZDY12-4(0.4)	ZDY21-4(0.8)	ZDY21-4(0.8)
Level of Protection	IP44 IP54	IP44 IP54	IP44 IP54	IP44 IP54	IP44 IP54	IP44 IP54
Type of Protection	116a-128b	116a-128b	120a-145c	120a-145c	125a-163c	140a-163c
Minimum Turning Radius(m)	1 1 1 1 1.8 2.5 3.2	1 1 1 1 1.8 2.5 3.2	1.2 1.2 1.5 2.0 2.8 3.5	1.2 1.2 1.5 2.0 2.8 3.5	1.5 1.5 1.5 2.5 3.0 4.0	1.5 1.5 1.5 2.5 3.0 4.0
Net weight(kg)	135 140 155 175 185 195	180 190 205 220 235 255	250 265 300 320 340 360	320 340 350 380 410 440	590 630 650 700 750 800	820 870 960 1015 1090 1125
